FLIR A320 Thailand Infrared Camera Specifications

Industrial Automation IR Camera


Imaging and optical data

Field of view (FOV) 25° x 18.8°
Focal Length 18mm
Spatial resolution 1.36mrad
Lens identification Automatic
F-number 1.3
Thermal sensitivity/ NETD <0.05°C @ + 30°C/ 50mK
Image frequency 9 Hz/ 30 Hz
Focus Automatic or manual (built in motor)
Digital zoom 1–8× continuous, interpolating zooming on images

Detector data

Detector type Focal Plane Array (FPA), uncooled microbolometer
Spectral range 7.5-13μm
IR resolution 320 x 240pixels
Detector pitch 25μm
Detector time constant Typical 12ms

Measurement

Measurement functions 4 Spotmeters, 4 Areas (Box, max/min/average/
position), Isotherm (above, below, interval), Reference
temperature, Temperature Difference (between
measurement functions, Reference temperature),
Measurement Mask Filter
Schedule response File sending (ftp), email (SMTP)
Measurement corrections Global and individual object parameters

Alarm

Alarm functions 6 automatic alarms on any selected measurement
function, Digital In, Camera temperature, timer
Response Digital Out, log, store image, file sending (ftp), email
(SMTP), notification

Storage of images

Image storage type Built-in memory for image storage
File formats Standard JPEG, 16-bit measurement data included
Compatible with FLIR software ThermaCAM Researcher 2.9
ThermaCAM Reporter 8
ThermaCAM QuickReport

Ethernet

Ethernet Control, result and image
Ethernet, type 100 Mbps
Ethernet, standard IEEE 802.3
Ethernet, connector type RJ-45
Ethernet, communication TCP/IP socket-based FLIR proprietary
Ethernet, video streaming MPEG-4, ISO/IEC 14496-1 MPEG-4 ASP@L5
Ethernet, power Power over Ethernet, PoE IEEE 802.3af class 0
Ethernet, image streaming 16-bit 320 × 240 pixels:
- Signal linear
- Temperature linear
- Radiometric
Ethernet, protocols TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, ftp,
SMTP, SMB (CIFS), DHCP, MDNS (Bonjour), uPnP

Digital input/output

Digital input, purpose Image tag (start/ stop/ general), Input ext. device (programmatically read)
Digital input 2 opto-isolated, 10-30 VDC
Digital ouput, purpose Output to ext. device
(programmatically set)
Digital ouput 2 opto-isolated, 10-30 VDC, max 100mA
Digital I/O, isolation voltage 500VRMS
Digital I/O, supply voltage 12/24 VDC, max 200 mA
Digital I/O, connector voltage 6-pole jackable screw terminal

Composite video

Video Composite video output, PAL and NTSC compatible
Video, connector type Standard BNC connector

Power system

External power operation 12/24 VDC, 24W absolute max
External power, connector type 2-pole jackable screw terminal
Voltage Allowed range 10-30 VDC

Environmental data

Operating temperature range -15°C to +50°C
Storage temperature range -40°C to +70°C
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C
EMC - EN 61000-6-2:2001 (Immunity)
- EN 61000-6-3:2001 (Emission)
- FCC 47 CFR Part 15 Class B (Emission)
Encapsulation IP 40 (IEC 60529)
Bump 25g (IEC 60068-2-29)
Vibration 2g (IEC 60068-2-6)

Physical data

Weight 0.7kg
Camera size (L x W x H) 170 x 70 x 70mm
Tripod mounting UNC1/4"-20 (on three sides)
Base mounting 2 x M4 thread mounting holes
(on three sides)
Housing materia Aluminium


FLIR A320 Thailand

The FLIR A320 camera offers an affordable and accurate temperature measurement solution for anyone who needs to solve problems that need built in "smartness" like analysis, alarm functionality and autonomous communication using standard protocols. The FLIR A320 camera also has all necessary features and functions to build distributed single- or multi-camera solutions utilizing standard Ethernet hardware and software protocols.
